AC/DC 24

Basic Info.

Model NO.	ZHRT1-A1
Protective Characteristics	Sealed Relay
Action Principle	Electronic Type
Size	Miniature
Type	Time Realy
Carton	100PCS
Key	DC Time Relay
Carton Size	495*240*171mm
Name	Time Relay
Weight	0.1kg
Transport Package	Carton Package
Specification	Size: 91.4*18*66.2mm
Trademark	AKMAN
Origin	Zhejiang China
HS Code	8536490000
Production Capacity	1000PCS/Week

Product Description

AC/DC 24-240V Time Delay off Relay for Emergency Stuff Timer Control

Model Selection Table

Model	Function	Rated supply voltage	Contact	Delay range
ZHRT1-A1	A.Power on,relay off,delay on	DC12V DC24V AC110V AC220V AC380V AC/DC24V~240V	1:1C/O, 2:2 C/O 2T:1C/O+1 instant C/O	0.1s~100h

Technical Parameters

Rated control supply voltage	DC12V,DC24V AC110V,AC220V,AC380V AC/DV 24V~240V 50/60Hz
Rated power consumption	AC:≤1.5VA DC: ≤1W
Delay range	0.1s~100h / multi range adjustment
Setting accuracy	≤5%
Repeat accuracy	≤0.2%
Repeat power-on interval	≥200ms
Electrical Life	105
Mechanical life	106
Altitube	≤2000m
Contact configuration capacity(A)	1C/0 8A;2 C/O 5A
IP Class	IP20
Class of pollution	3
Use category	AC-15
Contact capacity	Ue/le AC240V/1.5A,AC380V/0.95A
Output type	1C/O;2C/O;1C/O+1 instant C/O
DIN rail Standard	Width:35mm(IEC/EN60715)

Applications:Used in control panelcabinets and other electrical control circuit, according to the scheduled time automatically switch on or off the circuit.
Features:Built-in microcontrollers, 0.1s ~100h wide delay range, repeat accuracy≤0.2%. Knob setting,LED indicator shows working status.Variety of optional rated voltage. DIN rail mounting

Function diagramPower on,relay off,delay on
Wiring Diagram

Dimensions(mm)
